Research ArticleLumbar Spine

Modic Changes on Magnetic Resonance Imaging and Smoking History Predict Vascular Adherence During Anterior Lumbar Exposure

Gregory M. Malham, Nicholas Johnson and Matthew H. Claydon
International Journal of Spine Surgery December 2021, 15 (6) 1054-1059; DOI: https://doi.org/10.14444/8190

Abstract

Background Anterior approaches to surgically access the lumbar intervertebral discs are associated with a risk of developing major vascular injury and bleeding. The likelihood of injury increases in the presence of dense adherence between the disc annulus, vertebral periosteum, and vessels, which result from reactive inflammatory changes that cause fibrous scarring.

Objective To identify factors that predict vascular adherence, which may facilitate preoperative planning and technique modifications for anterior spine surgery.

Study Design Prospective study examining patients undergoing anterior retroperitoneal exposure for lumbar disc surgery.

Methods A total of 246 consecutive patients were enrolled in this study, all of whom had anterior retroperitoneal exposure for lumbar disc surgery. Patient demographics, smoking status, magnetic resonance imaging (MRI) findings, operative parameters, and dissection difficulty associated with vascular adherence were recorded. Current smokers were defined as those who smoked at the time of surgery or had ceased smoking <6 months before the operation. Patients were excluded if they were morbidly obese or had previously undergone anterior spine surgery or radiotherapy.

Results A multivariate regression analysis identified 2 significant risk factors for difficult dissections that are complicated by vascular adhesion: Modic Type 2 changes on MRI (P = 0.009) and any history of smoking (P = 0.007). Patients with Modic Type 2 changes or a smoking history were 2.1 and 2.2 times more likely to present with vascular adherence, respectively.

Conclusions Modic Type 2 changes on MRI and any smoking history can predict the adherence of large blood vessels to the anterior disc annulus, which enhances the difficulty of the dissection. These predictors could indicate to spinal surgeons that the patient has a 2-fold increased risk of vascular adherence.

Clinical Relevance Modic Type 2 changes on MRI and any smoking history can predict the adherence of large blood vessels to the anterior disc annulus, which enhances the difficulty of the dissection. These predictors could indicate to spinal surgeons that the patient has a 2-fold increased risk of vascular adherence during anterior lumbar exposure.

Level of Evidence 3.

INTRODUCTION

The anterior approach to lumbar disc surgery, for anterior lumbar interbody fusion (ALIF)1,2 or total disc replacement (TDR),3,4 is frequently applied, despite the inherent risks of developing major vascular injury and significant bleeding events.5,6 The vascular injury rate associated with anterior exposure ranges from 1.9% to 6.1%.7,8 Garg et al identified that the likelihood of experiencing vascular injury and increased blood loss was greater in males, patients with 2-level exposures, and those with a high body mass index (BMI). The most commonly injured vessels are the left common iliac vein, the inferior vena cava, and the ascending iliolumbar vein.9 Veins are more commonly injured than other blood vessels8 because of the close association between these structures and the target discs. A paucity of studies exist that explore the direct pathophysiology of these injuries. Moreover, reactive inflammatory changes can lead to the formation of fibrous scarring, which can form dense adherences between the disc annulus, vertebral periosteum, and blood vessels.6 We hypothesized that the formation of these adherences may represent a correlation between anterior surgical approaches and vascular injuries. To date, no published studies have identified the factors that predict the formation of these adhesions. In this study, we aimed to identify predictive factors in patients to identify vascular adherence to facilitate preoperative planning and technique modifications when performing anterior spine surgery.

MATERIALS AND METHODS

We conducted a prospective study, which included consecutive patients who underwent anterior spine surgery between 2011 and 2018 performed by a single spine surgeon (G.M.M.) and a single vascular surgeon (M.H.C.).

Inclusion/Exclusion Criteria

Indications for surgery included severe discogenic pain, radiculopathy, and Grade 1 or 2 degenerative or isthmic spondylolisthesis at L4-5 and/or L5-S1. Exclusion criteria included disease progression more severe than a 2-level disc disease, Grade 3 or 4 spondylolisthesis, significant iliac artery disease (ie, heavy calcification, aneurysmal, and/or severe stenosing atherosclerotic disease), morbid obesity (BMI ≥35), and previous complex/extensive retroperitoneal surgery or abdominal/pelvic radiotherapy.

Patient Characteristics

We collected patient data, including demographics, smoking status (current smokers were defined as patients who smoked at the time of surgery or had ceased smoking <6 months preoperatively), a previous history of spine operation, magnetic resonance imaging (MRI) findings, and operative parameters, including the level(s) of the operation and the difficulty of dissection due to vascular adherence.

Modic Changes

MRI signal intensity changes observed in the vertebral body marrow adjacent to endplates were classified into Modic Types 1, 2, and 3.10 Modic Type 1 changes describe a decreased signal intensity on T1-weighted images and an increased signal intensity on T2-weighted images; Modic Type 2 changes describe an increased signal intensity on both T1 and T2 images; and Modic Type 3 changes describe a decreased signal intensity on both T1 and T2 images. Two independent radiologists from the treating institution evaluated the MRI scans.

Surgical Techniques

The surgical techniques used for ALIF9 and TDR11 have been previously described elsewhere. A hybrid procedure can also be performed, consisting of ALIF at the L5-S1 level and TDR at the L4-5 level. The vascular surgeon performed a right-lower Rutherford-Morrison transverse incision using a retroperitoneal approach to access the L5-S1 level. For the L4-5 level and 2-level exposures, the vascular surgeon performed a midline lower abdominal incision using a left-sided retroperitoneal approach.

Difficulty of Dissection Due to Vascular Adherence

The vascular access surgeon was blinded to the patients’ smoking status and Modic changes on MRI. A binary, subjective evaluation of the degree of adherence was performed by the vascular surgeon, who classified each dissection as either standard (Figure 1) or difficult (Figure 2), depending on the forces and techniques required for vessel mobilization. A difficult dissection was defined by (1) the presence of broad vessel adherence, particularly to the left common iliac vein, the anterior vertebral body, and the disc, which was not attributable to perforating vessels and required increased dissection to mobilize the vessels; and (2) the necessity of using a subperiosteal approach to achieve safe separation and vessel mobilization.

Figure 1
Figure 1

Intraoperative photograph showing a standard vascular dissection between a vein (secured with vascular retraction pins) and the smooth periosteum to expose the L5-S1 disc with a midline pin.

Figure 2
Figure 2

Intraoperative photograph demonstrating a difficult vascular dissection that features thickened, “gritty” inflammation and the loss of the usual periosteal sheen, requiring a subperiosteal surgical approach to safely expose the L5-S1 disc.

Vascular Injury

Significant vascular injury was defined as the loss of >150 mL blood from a single major vessel or any injury to a major vessel that required suture repair. Blood loss was measured by a Cell Saver Autologous Blood Recovery System (Haemonetics Corp., Braintree, MA, USA), which was operated by a certified perfusionist.

Statistical Analysis

Multivariate regression analysis was conducted using SPSS software (Version 21.0, IBM Corp., Armonk, NY, USA). Statistical significance was set to P < 0.05.

RESULTS

Patient Characteristics

The patient demographics and treatment information are provided in Table 1. In this series, 17.5% (43 of 246) of patients were classified as having difficult dissections due to vascular adherence.

View this table:
Table 1

Patient demographic and treatment information (N = 246).

Factors Predicting Difficult Dissection

Multivariate regression analysis was performed to identify factors that predict a difficult dissection due to vascular adherence, which identified 2 significant risk factors: Modic Type 2 changes on MRI and smoking status (Table 2).

View this table:
Table 2

Multiple regression analysis of a difficult dissection.

Among patients with Modic Type 2 changes at the operative level, 16 of 57 patients (28%) were classified as difficult dissections, whereas only 25 of 189 patients (13%) without Type 2 changes were classified as difficult dissections (P = 0.014). Thus, patients with Modic Type 2 changes were 2.1-fold more likely to present with difficult dissection conditions than patients without Type 2 changes.

In addition, 9 of 38 patients (24%) who were current smokers and 19 of 83 patients (23%) who were ex-smokers were classified as difficult dissections, whereas only 13of 125 patients (10%) who never smoked presented with a difficult dissection (P = 0.01). Thus, patients with any smoking history were 2.2 times more likely to present with difficult dissection conditions than nonsmoking patients.

Vascular Injury

No significant vessel injuries occurred during this series. The main source of intraoperative blood loss was from epidural and median sacral vessels with the lumbosacral dissection. When the dissection was difficult, an increase in the measured blood loss occurred during both single-level and 2-level exposures. The average blood loss was 126.6 mL (standard dissection) vs 160.3 mL (difficult dissection, P = 0.5) for single-level exposures, and 189.9 mL (standard dissection) vs 347.5 mL (difficult dissection, P = 0.1) for 2-level exposures. The relationship between blood loss and dissection difficulty was not significant.

DISCUSSION

We have identified 2 independent factors that significantly correlate with the likelihood of dense adhesions between the disc annulus, vertebral periosteum, and adjacent vessels. The ability to predict such adherence, with the associated increased risk of major intraoperative hemorrhage would improve patient consent for surgery. This would allow improved preoperative planning, recruitment of vascular access surgeons, and the provision of equipment such as a Cell Saver. The consideration of alternative surgical approaches may be warranted, especially in patients who already have other relative contraindications such as obesity, concomitant arterial pathology (calcified atherosclerosis, tortuosity, or ectasia), or multiple previous abdominal operations.

In our study, a standard dissection was possible when the anterior surfaces of the vertebral bodies and discs were smooth, with a low sheen. Although occasional adherence focal points can be observed between the vessels and the vertebral bodies, particularly where the perforating vessels enter and exit the bone, the vessels, including the left common iliac vein that is in direct apposition to the vertebral bodies, could be easily separated from the periosteum and the surface of the disc with the application of peanut sponge forceps. In contrast, dissections were considered difficult when generalized adherence between these vessels, the vertebral body, and the disc were observed. This resulted in the veins being abnormally resistant to separation from these surfaces and required an increased dissection, which also increased the risk of venous injury. The loss of the characteristic sheen was also observed, with the final exposed surface appearing “gritty.” A continued effort to separate the vessels from the periosteum yielded an unacceptably high risk of developing major vascular injury during difficult dissections. To achieve a safe separation of the vessels from the target disc level, a deeper, subperiosteal approach must be used to develop a plane between the bone and periosteum, which allows adherent vessels to remain attached to the periosteum. This aforementioned approach is more appealing than that of a more superficial plane between the periosteum and the vein, which is more difficult and time-consuming.

Blood loss increased during difficult dissections due to adherence compared with standard dissections in both single-level and 2-level exposures. Notably, this increase was not significant. The vascular access surgeon employed advanced surgical techniques during difficult dissections to protect and mobilize, thus allowing for the safe exposure of the target disc. Had these advanced techniques not been employed, the continued efforts to separate the periosteum from the veins would likely have resulted in major vascular injury, and the consequent increase in blood loss would have been significant.

Michael Modic, at the Cleveland Clinic, described changes in MRI signal intensity, observed in the vertebral body marrow adjacent to endplates, as Type 1, 2, or 3 changes.11,12 Type 1 changes occur in approximately 4% of patients undergoing MRI for disc disease and represent acute inflammatory changes (eg, edema, hyperemia, and leucocyte infiltration) in the subchondral bone marrow. Type 2 changes occur in approximately 16% of patients and represent lipid replacement in the subchondral marrow. Type 3 changes are the least common (<1% of patients), and represent extensive bony sclerosis with little residual marrow.13 Type 1 but not Type 2 changes have been associated with increased lower back pain and disability,14 and Type I changes can progress to Type 2 changes over time.15 Modic changes are most commonly observed at L4-5 and L5-S1 and usually occur anteriorly.12

Although previous reports have correlated Modic changes with the pathology of the vertebral body marrow, no reports have associated Modic changes with perivertebral inflammation, scarring, or vessel adherence. In this study, we identified an association between intravertebral body Modic Type 2 changes, extravertebral inflammation, and scarring. The presence of Modic Type 2 changes suggested the chronicity of degenerative disc disease, which causes histopathological changes in the bone marrow. These Type 2 changes reflect chronic inflammation, which may result in dense scarring. This progression also appears to occur perivertebrally and causes scarring, and doubles the risk of vascular adherence.

We also found an association between vascular adherence and any history of smoking, even in the absence of Modic changes. This is possibly because smoking causes a chronic, low-grade, systemic inflammatory response that is associated with elevated levels of white blood cells and inflammatory mediators, such as C-reactive protein, fibrinogen, interleukin-6,16 and tumor necrosis factor-α.17 Cigarette smoke–induced inflammation affects the vascular endothelium and makes it more permeable to inflammatory cells that lead to damage caused by reactive oxygen species.18,19 Smoking also lowers the protective anti-inflammatory levels of nitric oxide in the endothelium.20 The resultant perivascular changes, combined with degenerative disc disease, can induce chronic inflammation, scarring, and vascular adherence.

Requiring patients to cease smoking before surgery is necessary for several reasons. Postoperative respiratory complications are reduced in patients who cease to smoke ≥4 weeks before surgical procedures.21 An increased benefit is observed if the cessation of smoking occurs ≥8 weeks before surgery.22,23 Postoperative wound-healing complications are also reduced in patients who cease to smoke >3 to 4 weeks prior to surgery.21,24 Because the greatest benefits associated with smoking cessation occur after cessation periods longer than 6 months,25 we defined ex-smokers as those who ceased to smoke >6 months preoperatively. Such a time period seemingly permitted for the smoking-induced inflammation and the resulting vascular adherence to subside. Therefore, any inflammation or vascular adherence encountered intraoperatively could reasonably be attributed to Modic changes alone. However, the effects of smoking are enduring, and even long durations of smoking abstinence are associated with an increased risk of developing vascular adherence. C-reactive protein levels remain significantly elevated in ex-smokers, from a period up to 10 to 20 years after smoking cessation. This suggests the persistence of a low-grade inflammatory response in former smokers.16 Consistent with this finding, we found that any smoking history doubled the risk of developing vascular adherence.

Ultimately, the causes of inflammation and vascular adherence may be multifactorial,18,19 as reflected by the increased adherence observed in patients in our series with a history of smoking but without Modic changes. The predominant inciting factor in some patients may be associated with vertebral inflammatory changes, as indicated by Modic changes, whereas perivascular inflammation may occur in other patients due to their smoking history. Disc pathology did not appear to be a major inciting factor.

For surgeons who are inexperienced in anterior spine exposure and do not utilize the services of a spinal access surgeon, the presence of Modic Type 2 changes, especially when combined with any smoking history, represents a valuable preoperative warning that indicates that a more experienced surgeon may be necessary. Similarly, in patients with various contraindications, the presence of Modic Type 2 changes and any smoking history may indicate that an alternative approach should be used. Although rare, major vascular injury can be fatal or threaten limb viability. Vascular adherence increases the risks of such an event occurring. This study illustrates 2 valuable preoperative measures that can be assessed to predict vascular adhesions that may lead to catastrophic vascular injury.

The strengths of this study include the use of a consistent surgical technique, performed by a single spine surgeon and a single vascular surgeon. The vascular surgeon was blinded to the patients’ smoking status and Modic changes on MRI to eliminate bias on the degree of operative vessel adherence. Two independent radiologists from the treating institution evaluated all MRI scans. A Cell Saver, operated by a certified perfusionist, measured blood loss.

However, the limitations of this study include a relatively small sample size compared with those featured in multicenter studies. In addition, another limitation is the lack of histopathological confirmations regarding the underlying causes of vascular adherence, given that no tissue was sampled for examination. One potential issue is that a vascular surgeon’s assessment of adherence and dissection difficulty may alter over time. However, the vascular surgeon that participated in our study had extensive prior experience with vascular exposure and is beyond the learning curve.9 At our institution, Modic Type 3 changes are not routinely reported; thus, we did not include these changes in our study.

CONCLUSION

In conclusion, Modic Type 2 changes on MRI and any smoking history predicted the adherence of large vessels to the anterior disc annulus, which enhanced the difficulty of the dissection. These predictors could alert a surgeon, undertaking an anterior exposure, that the patient may have a 2-fold increased likelihood of presenting with vascular adherence.

Footnotes

  • Funding The authors received no funding for the current study.

  • Declaration of Conflicting Interests Greg Malham: Globus (consultant), Device Technologies (travel), LifeHeathcare (travel). Nicholas Johnson: None. Matthew Claydon: Globus (consultant).

  • Ethics Approval This study had institutional ethics and research approval.
